1. The rated slip is 1.5～3%. For centrifugal machineries with load characteristics of M∝n2, stepless speed regulation over range of 1～1/5 is available. For constant torque drives with M=C a range of 1～1/3 may be provided.
2. The alphabet W added behind the type No. denotes fluid coupling for outdoor installation.
3. The alphabet B added behind the type No. denotes fluid coupling installed at coal mine.
|
型號(hào) Type No. |
輸入轉(zhuǎn)速Input speed(r/min) | 傳遞功率Power transm.(KW) |
L |
h |
A |
B |
C |
d1 d2 |
L1 L2 |
H | W1 | W2 | n-d |
重量 Weight(kg) |
|
YOTGCD560 |
1000 |
35~100 |
930 |
700 |
3x225 |
1140 |
93.5 |
Ø75 |
140 |
1250 |
900 |
900 |
8-Ø22 |
850 |
|
1500 |
115~340 |
|||||||||||||
|
YOTGCD650 |
1000 |
75~215 |
1100 |
700 |
3x225 |
1140 |
113.5 |
Ø85 |
150 |
1505 |
900 |
900 |
8-Ø22 |
1050 |
|
1500 |
250~730 |
|||||||||||||
|
YOTGCD750 |
1000 |
150~440 |
1200 |
750 |
4x200 |
1450 |
152.5 |
Ø100 |
150 |
1555 |
950 |
755 |
10-Ø22 |
1100 |
|
1500 |
510~1480 |
|||||||||||||
|
YOTGCD800 |
1000 |
230~610 |
1300 |
750 |
4x200 |
1450 |
202.5 |
Ø120 |
210 |
1555 |
1050 |
755 |
10-Ø22 |
1700 |
|
1500 |
740~2080 |
|||||||||||||
|
YOTGCD875 |
750 |
150~400 |
1400 |
850 |
3x320 |
1550 |
220 |
Ø125 |
250 |
1500 |
1050 |
800 |
8-Ø28 |
2900 |
|
1000 |
365~960 |
Ø125 |
1000 | 810 | 2675 | |||||||||
| 1500 | 1160~3260 |
Ø135 |
1050 | 800 | 2900 | |||||||||
|
YOTGCD1000 |
750 |
285~750 |
1500 |
900 |
3x320 |
1650 |
220 |
Ø135 |
250 |
1595 |
1150 |
855 |
8-Ø28 |
3600 |
|
1000 |
640~1860 |
1902 | 1180 | 866 | 2900 | |||||||||
|
YOTGCD1050 |
750 |
360~955 |
1650 |
1150 |
4x320 |
1750 |
185 |
Ø150 |
250 |
1938 |
1200 |
925 |
10-Ø35 |
4300 |
|
1000 |
815~2300 |
|||||||||||||
|
YOTGCD1150 |
600 |
360~955 |
1650 |
1150 |
4x320 |
1750 |
185 |
Ø150 |
250 |
1938 |
1200 |
925 |
10-Ø35 |
4700 |
| 750 | 715~1865 |
Ø150 |
1210 | 925 | 5000 | |||||||||
| 1000 | 1700~4400 |
Ø160 |
1062 | 1062 | 4800 |
