1. This type of fluid coupling is with further enlarged delay chamber.
2．The size of brake pulley could be decided through consultation.
| 型號Type No. |
Lmin |
D | L1 | 輸入端Input side | 輸出端Output side | 制動輪Brake pulley | 充油量Oil filling(L) | 重量(不包括油)Weight w/o oil(kg) | 最高轉(zhuǎn)速Max.speed(r/min) |
過載系數(shù) Overload ratio |
||||
| d1max | H1max | d2max | H2max | D1 | B | max. | min. | |||||||
| YOXYZ562 | 770 | Ø634 | 15 | Ø90 | 170 | Ø100 | 180 | Ø400 | 190 | 27 | 13.5 | 260 | 1500 | 1.1～2.35 |
| YOXYZ650 | 914 | Ø740 | 15 | Ø125 | 225 | Ø130 | 200 | Ø500 | 210 | 46 | 23 | 440 | 1500 | 1.1～2.35 |
