1. This type of fluid coupling is with further enlarged delay chamber.
2. It is more easy to align, install and dismount.
3. The size of brake pulley could be decided through consultation.
4. The L2 dimension is referenced to YOXE size setting.
| 型號(hào)Type No. | D | 輸入端Input side | 輸出端Output side | 制動(dòng)輪Brake pulley | 充油量Oil filling(L) | 重量(不包括油)Weight w/o oil(kg) | 最高轉(zhuǎn)速M(fèi)ax.speed(r/min) |
過載系數(shù) Overload ratio |
||||
| d1max | H1max | d2max | H2max | D1 | B | max. | min. | |||||
| YOXYEZ450 | Ø530 | Ø75 | 140 | Ø75 | 140 | Ø315 | 150 | 13 | 6.5 | 148 | 1500 | 1.1～2.35 |
| YOXYEZ562 | Ø590 | Ø85 | 170 | Ø85 | 145 | Ø400 | 170 | 19.2 | 9.6 | 155 | 1500 | 1.1～2.35 |
| YOXYEZ650 | Ø634 | Ø100 | 180 | Ø130 | 170 | Ø400 | 170 | 27 | 13.5 | 260 | 1500 | 1.1～2.35 |
| YOXYEZ750 | Ø842 | Ø140 | 245 | Ø150 | 240 | Ø630 | 265 | 68 | 34 | 615 | 1500 | 1.1～2.35 |
